Home ProductsTransparent Glass LED Screen

Stage P3.9 Slim Transparent Glass LED Screen / Indoor Transparent LED Video Wall

Stage P3.9 Slim Transparent Glass LED Screen / Indoor Transparent LED Video Wall

    • Stage P3.9 Slim Transparent Glass LED Screen / Indoor Transparent LED Video Wall
    • Stage P3.9 Slim Transparent Glass LED Screen / Indoor Transparent LED Video Wall
    • Stage P3.9 Slim Transparent Glass LED Screen / Indoor Transparent LED Video Wall
  • Stage P3.9 Slim Transparent Glass LED Screen / Indoor Transparent LED Video Wall

    Product Details:

    Place of Origin: China
    Brand Name: GBLED
    Certification: CE FCC ROHS UL
    Model Number: GRT-3.91

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Flight case
    Delivery Time: 15 working days after received your payment
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 5,000pcs per month
    Contact Now
    Detailed Product Description
    Pixel Pitch: 3.9mm Brightness: 1000 Nits
    Materials: Die-casting Aluminum Panel Size: 500 X 1000mm
    Connector: Fast Aviation Connector For Power And Data Installation: Hanging And Floor Stand
    Lock System: Fast Lock System

    Indoor P3.9 Slim Transparent Glass LED Screen / Transparent LED Video Wall For Stage​


    Description:

    1. High transparency up to 85%.
    2. Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive.
    3. Ultra slim with 7mm thickness.
    4. Light with only 7kg/panel.
    5. Double projection with acrylic in front and rear.
    6. Die-casting aluminum with high precision.
    7. Fast lock system design and fast aviation connector for power and data.
    8. 2 years warranty, easy to install & maintenance.
    9. CE, ROHS, FCC.


    Products Advantages:
    1) Price Advantage: we have the best competitive price in the market, also better quality.
    2) Performance Advantage: Best Equality, high consistency, Big viewing angle,
    3) Quality advantage: From material to finished product, from design to produce, we control all steps. That's the guarantee of the quality and reliability.
    4) Service advantage: Better service in the same situation, better cooperation in the same service!

    Specifications:



    TRANSPARENT LED DISPLAY SERIES PARAMETER
    Standard Brightness/High Brightness
    TypeG3.91-5G3.91-7.81G7.81-7.81G7.81-15.62G710.4-10.4
    Pixel Pitch

    3.91mm(H)
    5mm(V)

    3.91mm(H)
    7.81mm(V)

    7.81mm(H)
    7.81mm(V)

    7.81mm(H)
    15.62mm(V)

    10.4mm(H)
    10.4mm(V)


    Pixel Density(pixel/sqm)51,20032,76816,3848,1929,216
    Panel Weight15kgs15kgs15kgs15kgs15kgs
    Protection Level(front/back)IP43IP43IP43IP43IP43
    Panel Power Consumption(max./ave.)400/150400/150400/150400/150400/150
    Viewing Angle(h×v)120°/120°120°/120°120°/120°120°/120°120°/120°

    Brightness
    (adjustable)

    1200nits/
    5000nits

    1200nits/
    5000nits

    1200nits/5000nits1200nits/5000nits1200nits/5000nits
    LED Type SMD 3-in-1
    Panel Size 1000mm x 1000mm /500mm x 1000mm
    Maintenance Method from
    Panel Material Aluminum+ Aacrylic
    Brightness/Color Calibration Yes
    Refresh Rate ≥1920Hz
    Grey Level(adjustable) 12-16bit
    Color Temperature(adjustable) 6500K
    Operating Voltage AC220V(50~60Hz)
    Contrast Ratio 2000:1
    Working Humidity(rh) 10 ~ 80%
    Working Temperature -20℃~50℃
    Life Time(hrs) ≥100,000
    Color Uniformity ±0.0035 Cx,Cy
    Luminance Uniformity ≥97.5%
    Certification ETL.CE-TUV. RoHS.FCC.CCC

    Version:V1.0



    Good service After-sale
    1. Two years warranty for the whole system except human factor and force majeure
    2. One year quality warranty, lifetime maintenance, and guarantee the maintenance time in contract.
    3. During the warranty period: solve problems for users through the phone, fax or E-Mail. Update the software free of charge.
    4. As to the product quality problems caused by design, manufacture, installation technology, material, the replacement and maintenance are free. The system damage caused by force majeure(flood, fire, earthquake, war and so on) as well as users) man-made disturbance(construction, cleaning ) should be coordinate by both sides to solve.
    5. Life-long maintenance for the system: after the guarantee, we only charge the cost of hardware


    Our company
    Our product quality management is strictly adhering to the ISO9001: 2008 certifications system and 7S management standard, to seek for greater perfection, which exerts profound influence on standardization of LED industry.GBLED is a national new high-tech enterprise,which owns number of national patents and has been cited as "Shenzhen Flat Panel Display Industry Association", "Member of Shenzhen SME Development Association", "Member of Semi-conductor and Lighting Promotion Association", "Member of Shenzhen Electronic Chamber of Commerce", "Member of China Optics and Optoelectronics Industry Association and LED Display Applications Branch Association", "Certified Supplier of Made-in-China" etc.
    With an outstanding business performance and good social reputation,We has won respect from various circles of society, and acquired the "2009-2010 Excellent LED Display Application Engineering", "China Well-known Enterprise", "AAA Quality, Service and Prestige Unit", "China Top 100 Enterprise", "Guangdong China Top 10 Enterprise", "Shenzhen Well known Brand Enterprise", "National New High-tech Enterprise" etc.
    Stage P3.9 Slim Transparent Glass LED Screen / Indoor Transparent LED Video Wall
    Stage P3.9 Slim Transparent Glass LED Screen / Indoor Transparent LED Video Wall
    Stage P3.9 Slim Transparent Glass LED Screen / Indoor Transparent LED Video Wall
    Stage P3.9 Slim Transparent Glass LED Screen / Indoor Transparent LED Video Wall
