High Brightness Indoor Advertising LED Display P3MM For Shopping Center

High Brightness Indoor Advertising LED Display P3MM For Shopping Center

    • High Brightness Indoor Advertising LED Display P3MM For Shopping Center
    • High Brightness Indoor Advertising LED Display P3MM For Shopping Center
  • High Brightness Indoor Advertising LED Display P3MM For Shopping Center

    Product Details:

    Place of Origin: CHINA
    Brand Name: GBLED
    Certification: CE FCC ROHS UL
    Model Number: GFI-3

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Wooden box
    Delivery Time: 15-20 working days after receiving the deposit
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 5000m2 per month
    Contact Now
    Detailed Product Description
    Pixel Pitch: 3mm Panel Size: 576mm X 576mm
    Brightness: 1000 Nits Materials: Steel Cabinet With Backdoor
    Certification: CE FCC ROHS UL Origin: China

    High Brightness Indoor Advertising LED Display P3MM For Shopping Center



    Description:
    1. Panel size 576mm x 576mm
    2. Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive.
    3. Light with only 9 kg/ panel
    4. High refresh rate.
    5. Steel cabinet high precision.
    6. 2 years warranty, easy to install & maintenance.
    7. CE, ROHS, FCC.


    Specifications:


    Fixed Install (Indoor) Series Parameter
    Type P3 P4 P5 P6
    Module Pixel Configuration 2121 2121 3528 3528
    Pixel Pitch (mm) 3 4 5 6
    Module Size (W*H) 192*96 256*128 320*160 192*192
    Module Resolution (W*H) 64*32 64*32 64*32 32*32
    Panel Panel Size (W*H) 576*576 512*512 640*640 576*576
    Panel Area (㎡) 0.33 0.26 0.41 0.33
    Panel Resolution (W*H) 192*192 128*128 128*128 96*96
    Panel Weight (kg) 40
    Maintenance Method Rear
    Pixel Denity (Dots/㎡) 111111 62500 40000 27777
    Brightness (cd/㎡) 1200 1200 1500 1500
    Refresh Rate (Hz) ≤1200
    Grey Level (Bit) 12~16
    Driving Mode (Scan) 1/16 1/16 1/16 1/8
    Color Temperature (K) 6500~9000 Adjustable
    Horizontal/Vertical Viewing Angle (°) 140/140
    Max./Ave.Power Consumption (Per Panel) 700/280 600/240 600/240 600/240
    Operating Voltage AC90~240V(50~60Hz)
    Contrast Ratio 1/5000 1/5000 1/2000 1/2000
    Application Working Temperature (℃) -25~45
    Working Humidity (RH) 10~ 85% No Condensation
    Blind Light Rate 1/1,000,000
    Working Life Span (hrs) ≥100,000
    Certificate CCC.ETL/UL.CE-TUV.FCC.ROHS
    Version:V1.0



    Good service After-sale
    1. Two years warranty for the whole system except human factor and force majeure
    2. One year quality warranty, lifetime maintenance, and guarantee the maintenance time in contract.
    3. During the warranty period: solve problems for users through the phone, fax or E-Mail. Update the software free of charge.
    4. As to the product quality problems caused by design, manufacture, installation technology, material, the replacement and maintenance are free. The system damage caused by force majeure(flood, fire, earthquake, war and so on) as well as users) man-made disturbance(construction, cleaning ) should be coordinate by both sides to solve.
    5. Life-long maintenance for the system: after the guarantee, we only charge the cost of hardware





    Our company:



    We are the professional LED screen service provider, was Established in 2004 with a registered capital of more than $ 10 Million, now ranks the leading manufacturer of LED display. Since its inception, our company has kept rapid growth; Our products have been sold to more than 130 countries and regions, and the brand GBLED has got highly recognition in the world.

    High Brightness Indoor Advertising LED Display P3MM For Shopping Center

    As always, on "Action speaks louder than words" as its brand business philosophy. Working hard and being a magnanimous man. We are been utilizing the advanced technologies and pursuing innovation to produce the best quality product, and regarding every order as our vanity project. To make our product perfect, we introduce the most advanced production equipments and detecting facilities, So as to maintain a strict quality standard of every production process. Thanks to those efforts, our products have passed many certificates, such as, CE, UCS, CCC, FCC approval etc.

    Our product quality management is strictly adhering to the ISO9001: 2008 certifications system and 7S management standard, to seek for greater perfection, which exerts profound influence on standardization of LED industry.GBLED is a national new high-tech enterprise,which owns number of national patents and has been cited as "Shenzhen Flat Panel Display Industry Association", "Member of Shenzhen SME Development Association", "Member of Semi-conductor and Lighting Promotion Association", "Member of Shenzhen Electronic Chamber of Commerce", "Member of China Optics and Optoelectronics Industry Association and LED Display Applications Branch Association", "Certified Supplier of Made-in-China" etc.

    With an outstanding business performance and good social reputation,We has won respect from various circles of society, and acquired the "2009-2010 Excellent LED Display Application Engineering", "China Well-known Enterprise", "AAA Quality, Service and Prestige Unit", "China Top 100 Enterprise", "Guangdong China Top 10 Enterprise", "Shenzhen Well known Brand Enterprise", "National New High-tech Enterprise" etc.

    Here we promise that, every client, every order and every feedback will be valued byGift Booking. Let's hand in hand, regarding "Showing the beauty of the world" as our mission, and creating a more colorful and brighter world.


    High Brightness Indoor Advertising LED Display P3MM For Shopping Center
    High Brightness Indoor Advertising LED Display P3MM For Shopping Center
    High Brightness Indoor Advertising LED Display P3MM For Shopping Center
    High Brightness Indoor Advertising LED Display P3MM For Shopping Center
