• P7.62 Indoor Advertising LED Display Billboard High Brightness 488mm X 244mm Module
P7.62 Indoor Advertising LED Display Billboard High Brightness 488mm X 244mm Module

P7.62 Indoor Advertising LED Display Billboard High Brightness 488mm X 244mm Module

Product Details:

Place of Origin: China
Brand Name: GBLED
Certification: CE/ROHS/FCC
Model Number: P7.62

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Wooden Case, Flight Case
Delivery Time: 10-30 workingdays
Payment Terms: T/T, Western Union
Get Best Price Contact Now

Detail Information

Module Size: 488mm*244mm Pixel Pitch: 7.62mm
Color: Full Color Physical Density: 17222/m2
Pixel Configuration: 1R1G1B Packaged Type Of LED: SMD
Brightness(cd/m²): 3500
High Light:

indoor advertising screens


indoor advertising led display screen

Product Description

P7.62 Indoor Advertising LED Display Billboard High Brightness 488mm X 244mm Module




Items P7.62 Indoor Full Color Display
Module Pixel Pitch 7.62mm
Pixel Density(dot/m²) 17222
Pixel Configuration 1R1G1B
Packaged Type of LED SMD
Module Size(mm) 244 * 244 or 488 * 244 mm
Module Resolution 32 * 32 or 64 * 32
Brightness(cd/m²) 3500
Max Power Consumption(w/m²) 700
Best Viewing Distance(m) 7-21
Viewing Angle 120°V/120°H
Drive Mode Constant Current drive 1/8 scan
Driving Driving IC MBI5026 / MBI5024
Frame-change Frequency ≥60 Hz/s
Refresh Rate ≥600Hz/s
Gray Grade Level 4096 grades
Color 65536kinds of colors
Display Mode 1024*768
Control System Synchronization Control
Transmission Distance Reticle≤100M;Multi-mode Fiber≤500M;Single-mode Fiber≤10000M
Out of Control Rate≤0.0001
Lifespan ≥100000H
Driving Power 5V
Working Voltage AC220V±10% 47HZ~60hz
Working Temperature -10ºC~+55ºC
Working Humidity 5%RH~85%RH



Features of our LED display:


1. High brightness /refresh rate


2. Vivid and colorful display


3. Impact resistant,adapt to kinds of weather


4. Quick response


5. Energy-saving, high luminance,low thermal, environment-friendly


6. Low deficiency rate and low cost


7. Support various interfaces and signal sources, support multi-transmission methods, network control and automatic brightness control





Q1: When is the delivery time?


A1: we will accomplish manufacturing within 15 days after receiving the deposit.


Q2: What is the payment method?


A2: We support a variety of payment methods, the most common is the TT.


Q3: What's the pixel pitch for Outdoor LED Display Screen?


A3: Indoor (P2.5mm / P3mm/P4mmP / P5mm/P6mm)


Q5: Can it play HD video?


A5: Yes, it can realize HD video function with Linsn controlling system.


Q7: How about the size of project?


A7: Please offer the size with "width by height" of project. We will offer the suitable solution for your project size
Q8: How about your service?


1. Lifetime free maintenance and upgrade.


2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.


3. Customer satisfaction tracking report.


4. Free technician training.


5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.


6. Special service for big project, such as stadium, exhibitions, squares and so on.


After Services:


We promise we provide 2 years warranty for free maintain for our products and full life tracking service.

1. During the warranty period, we will repair the equipment free of charge unconditionally if the problem is caused by product quality or production and installation problem.

2. When the warranty expires. we continue to provide maintenance service for whole life of the equipment with relative service/material cost paid.

3. Updating software service is free of charge.

4. Quick respond and repair and help promised by sending technicians to help test and repair on site within 36 hours after customer’s request.

5. We will finish repairing within 5 days after defective equipment sent back to us

• Site instruction service of installation is available.




Basic promise:
A: Full automatic production to control our high quality, best color consistency and get better performance.
B: Energy saving, low power consumption and long lifespan 100,000 hours (about 10 years).
C: We guarantee that the equipment we provide are brand new, complete and unused.
D: Good heat dissipation capability and high waterproof because of the unique design of vent fan (like shutter).
E: Our quality control throughout every process from materials-production- test-package-delivery



Our company:


We are the professional LED screen service provider, was Established in 2004 with a registered capital of more than $ 10 Million, now ranks the leading manufacturer of LED display. Since its inception, our company has kept rapid growth; Our products have been sold to more than 130 countries and regions, and the brand GBLED has got highly recognition in the world.

As always, on "Action speaks louder than words" as its brand business philosophy. Working hard and being a magnanimous man. We are been utilizing the advanced technologies and pursuing innovation to produce the best quality product, and regarding every order as our vanity project. To make our product perfect, we introduce the most advanced production equipments and detecting facilities, So as to maintain a strict quality standard of every production process. Thanks to those efforts, our products have passed many certificates, such as, CE, UCS, CCC, FCC approval etc.

Our product quality management is strictly adhering to the ISO9001: 2008 certifications system and 7S management standard, to seek for greater perfection, which exerts profound influence on standardization of LED industry.GBLED is a national new high-tech enterprise,which owns number of national patents and has been cited as "Shenzhen Flat Panel Display Industry Association", "Member of Shenzhen SME Development Association", "Member of Semi-conductor and Lighting Promotion Association", "Member of Shenzhen Electronic Chamber of Commerce", "Member of China Optics and Optoelectronics Industry Association and LED Display Applications Branch Association", "Certified Supplier of Made-in-China" etc.

With an outstanding business performance and good social reputation,We has won respect from various circles of society, and acquired the "2009-2010 Excellent LED Display Application Engineering", "China Well-known Enterprise", "AAA Quality, Service and Prestige Unit", "China Top 100 Enterprise", "Guangdong China Top 10 Enterprise", "Shenzhen Well known Brand Enterprise", "National New High-tech Enterprise" etc.

Here we promise that, every client, every order and every feedback will be valued byGift Booking. Let's hand in hand, regarding "Showing the beauty of the world" as our mission, and creating a more colorful and brighter world.
