Professional P10 Outdoor Full Color Led Display For Sports Advertising
Product Details:
| Certification: | CE/RoHS/FCC/ETL etc. |
| Model Number: | E1000D |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Flight case or wooden box |
| Delivery Time: | 15 working days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 5000 sqms per month |
|
Detail Information |
|||
| Pixel Pitch (mm): | 10.0 | Configuration: | DIP346 |
|---|---|---|---|
| Module Dimension (mm): | 320 X 320 | Module Weight(kg): | 2.08 |
| Power Requirements: | AC90~264V, 47~63Hz | Signal Transmission Distance: | CAT Cable:<100m;Single Mode Fiber:<10km |
| Highlight: | stadium led screens,stadium advertising boards |
||
Product Description
Large Viewing Angle Stadium LED Screen 10mm For Sports Advertising
Specification:
|
Model |
E1000D |
|
Pixel pitch (mm) |
10.0 |
|
Configuration |
DIP346 |
|
Module dimension (mm) |
320 x 320 |
|
Module weight(kg) |
2.08 |
|
Panel dimension(mm) |
1280x960x120 |
|
Panel weight(kg) |
50 |
|
Pixel density(dots/㎡) |
10000 |
|
Flatness error(mm) |
≤0.1 |
|
Viewing angle(°) |
140/100(Horizontal/Vertical) |
|
Brightness(cd/㎡) |
>7500 |
|
Contrast |
4000:1 |
|
Repetition frequency(Hz) |
50/60 |
|
Refresh frequency(Hz) |
1920 |
|
Gray scale(bit) |
14 |
|
Ave. power(W/㎡) |
200 |
|
Max power(W/㎡) |
698 |
|
Working temp./humidity |
-20~65℃/10%~90%RH |
|
Storing temp./humidity |
-20~65℃/10%~90%RH |
|
Protection |
IP65/IP54 |
|
Scanning |
1/4 |
|
Power requirements |
AC90~264V, 47~63Hz |
|
Signal Transmission Distance |
CAT cable:<100m;Single mode fiber:<10km |
|
Installation type |
Fix |
|
Life time(hrs) |
100,000 |
|
Certificate |
CCC/TUV-CE/ETL, etc. |
Features:
1. Professional lock design makes seamless connection available;
2. High brightness;
3. Information source can be camera, video, VCD, DVD, LD, TV and so on; Clear picture without flicker and distortion;
4. Black LED and light absorbing mask patent increase the display effect ;
5. Unique thermal structure with aluminum plate, stable and reliable;
6. Light, thin and intensive design offers more space to be creative ;
Advantage:
1) Price Advantage: we have the best competitive price and good products quality at the market
2) Performance Advantage: Best Equality, high consistency, big viewing angle, can repair each led lamps
3) Quality advantage: From material to finished product, from design to produce, we control all steps, that''s the guarantee of the quality and reliability.
4) Service advantage: Better service at same situation, better cooperation at same service!
After-Sale Service
1. Two year warranty , Lifetime free maintenance.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
Application:
1) Full color LED display : Equally or compactly make the red, green, blue color in one dot, equally distribute at the panel, so make the whole display
2) Usually apply to sports stadiums.
