SMD 3 In 1 Outdoor Transparent LED Display P10.4mm With 5000 Nits Brightness
Product Details:
Certification: | CE FCC ROHS UL |
Model Number: | GFT-10.4 |
Payment & Shipping Terms:
Minimum Order Quantity: | Negotiation |
---|---|
Price: | Negotiation |
Packaging Details: | Wooden Box |
Delivery Time: | 15 working days after received your payment |
Payment Terms: | T/T, Western Union, MoneyGram |
Supply Ability: | 5,000pcs per month |
Detail Information |
|||
Pixel Pitch: | 10.4mm | Brightness: | 5000 Nits |
---|---|---|---|
Panel Size: | 1000mm X 1000mm | Panel Weight: | 16kg |
Highlight: | led transparent screen,clear led screen |
Product Description
High Quality Outdoor P10.4mm transparent led display with 5000 nits brightness
Description:
1. High transparency up to 85%.
2. Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive.
3. Ultra slim with 7mm thickness.
4. Light with only 7kg/panel.
5. Double projection with acrylic in front and rear.
6. 2 years warranty, easy to install & maintenance.
7. CE, ROHS, FCC.
Features:
1. 40000 pixel dots per square meter resolution.
2. With super-high brightness LED, high contrast.
3. Unequalled high brightness and stable performance lead long lifespan and low power consumption.Accurate color uniformity and smoother,flicker-free video displaying.
4. 16,777,216 colors combine with 256 level gray scale by each Red,Green,and Blue LED.
5. Extreme viewing angle by 3 IN 1 SMD,better color mixture and gorgeous image quality.
6. Latest LED technology and control method accepted, make excellent performance with attractive price.
Specifications:
TRANSPARENT LED DISPLAY SERIES PARAMETER | ||||||
Standard Brightness/High Brightness | ||||||
Type | G3.91-5 | G3.91-7.81 | G7.81-7.81 | G7.81-15.62 | G710.4-10.4 | |
Pixel Pitch |
3.91mm(H) 5mm(V) |
3.91mm(H) 7.81mm(V) |
7.81mm(H) 7.81mm(V) |
7.81mm(H) 15.62mm(V) |
10.4mm(H) 10.4mm(V) |
|
Pixel Density(pixel/sqm) | 51,200 | 32,768 | 16,384 | 8,192 | 9,216 | |
Panel Weight | 15kgs | 15kgs | 15kgs | 15kgs | 15kgs | |
Protection Level(front/back) | IP43 | IP43 | IP43 | IP43 | IP43 | |
Panel Power Consumption(max./ave.) | 400/150 | 400/150 | 400/150 | 400/150 | 400/150 | |
Viewing Angle(h×v) | 120°/120° | 120°/120° | 120°/120° | 120°/120° | 120°/120° | |
Brightness |
1200nits/ |
1200nits/ |
1200nits/ |
1200nits/5000nits | 1200nits/5000nits | |
LED Type | SMD 3-in-1 | |||||
Panel Size | 1000mm x 1000mm /500mm x 1000mm | |||||
Maintenance Method | from | |||||
Panel Material | Aluminum+ Aacrylic | |||||
Brightness/Color Calibration | Yes | |||||
Refresh Rate | ≥1920Hz | |||||
Grey Level(adjustable) | 12-16bit | |||||
Color Temperature(adjustable) | 6500K | |||||
Operating Voltage | AC220V(50~60Hz) | |||||
Contrast Ratio | 2000:1 | |||||
Working Humidity(rh) | 10 ~ 80% | |||||
Working Temperature | -20℃~50℃ | |||||
Life Time(hrs) | ≥100,000 | |||||
Color Uniformity | ±0.0035 Cx,Cy | |||||
Luminance Uniformity | ≥97.5% | |||||
Certification | ETL.CE-TUV. RoHS.FCC.CCC | |||||
Version:V1.0 |
Good service After-sale
1. Two years warranty for the whole system except human factor and force majeure
2. One year quality warranty, lifetime maintenance, and guarantee the maintenance time in contract.
3. During the warranty period: solve problems for users through the phone, fax or E-Mail. Update the software free of charge.
4. As to the product quality problems caused by design, manufacture, installation technology, material, the replacement and maintenance are free. The system damage caused by force majeure(flood, fire, earthquake, war and so on) as well as users) man-made disturbance(construction, cleaning ) should be coordinate by both sides to solve.
5. Life-long maintenance for the system: after the guarantee, we only charge the cost of hardware.
Our compamy
Our product quality management is strictly adhering to the ISO9001: 2008 certifications system and 7S management standard, to seek for greater perfection, which exerts profound influence on standardization of LED industry.GBLED is a national new high-tech enterprise,which owns number of national patents and has been cited as "Shenzhen Flat Panel Display Industry Association", "Member of Shenzhen SME Development Association", "Member of Semi-conductor and Lighting Promotion Association", "Member of Shenzhen Electronic Chamber of Commerce", "Member of China Optics and Optoelectronics Industry Association and LED Display Applications Branch Association", "Certified Supplier of Made-in-China" etc.
