Ph4 Wedding / Night Club Indoor Advertising LED Display Hire Refresh Frequency ≥ 600
Product Details:
| Place of Origin: | China |
| Brand Name: | GBLED |
| Certification: | CE/ROHS/FCC |
| Model Number: | P4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden case, flight case |
| Delivery Time: | 15 working days after receiving the deposit |
| Payment Terms: | T/T, Western Union |
|
Detail Information |
|||
| Pixel Pitch: | 4 Mm | Module Size: | 256 * 128 Mm |
|---|---|---|---|
| Brightness: | 1500cd / Sqm | Scan Mode: | 1/16 Scanning |
| Physical Density: | 62500 Dots / ㎡ | Module Resoultion: | 64 * 32 |
| Led Package: | SMD 2121 | Pixel Configuration: | 1R1G1B |
| High Light: | indoor advertising screens,indoor advertising led display screen |
||
Product Description
Ph4 Wedding / Night Club Indoor LED Displays Hire Refresh Frequency ≥ 600
Specifications:
| ※Module parameters | ||||
| Technical parameters | UNIT | parameters | ||
| Pixel pitch | MM | 4 | ||
| Panel size | MM | L256*H128*T13 | ||
| Physical density | /M2 | 62500 | ||
| Pixel configuration | R/G/B | 1,1,1 | ||
| Driving method | Constant current 1/16scan | |||
| LED Encapsulation | SMD | 2121 black light | ||
| Display resolution | DOTS | 64X32=2048 | ||
| Module weight | KG | 0.20 | ||
| Module port | HUB75-B | |||
| Module working voltage | VDC | 5 | ||
| Module consumption | W | 30 | ||
| ※Screen parameters | ||||
| Viewing angle | Deg. | 140 ° | ||
| Option distance | M | 4-50 | ||
| Driving device | 2026/5020 | |||
| Every square metre module | PCS | 30.52 | ||
| Maximum power | W/ M2 | 1000 | ||
| Frame Frequency | HZ/S | ≥60 | ||
| Refresh frequency | HZ/S | ≥600 | ||
| Equilibrium brightness | CD/ M2 | ≥1800 | ||
| Working environment temperature) | 0C | -10~60 | ||
| Working environment humidity | RH | 10%～70% | ||
| Display working voltage | VAC | AC46～54HZ,220V±15%/110V±15% | ||
| Colour temperature | 8500K-11500K | |||
| Gray scale/color | ≥16.7M color | |||
| Input signal | RF S-Video RGB etc | |||
| Control system | PCTV nonlinearity card,DVI display card,Linsn control system | |||
| Mean free error time | HOURS | ＞5000 | ||
| Life span | HOURS | 100000 | ||
| Lamp failure frequency | ＜0.0001 | |||
| Antijam | IEC801 | |||
| Safety | GB4793 | |||
| Resist the electricity | 1500V last 1min No breakdown | |||
| Steel box weight | KG/ M2 | 40 (standard steel box) | ||
| IP rating | The back IP40,The front IP50 | |||
| Cabinet size (for reference) | mm | L768Xh768x80 | ||
Features:
1. P2.5/P3/P4/ P5/ P6/ P7.62 and P10 LED modules are available.
2. Single color, Bi-color and Full color modules available.
3. Waterproof IP65 rating, guaranteeing our product's stable broadcasting in harshest weather condition.
4. Strict system control and pixel to pixel correction make the image smooth and uniformity.
5. Able to show a variety of content of video, animation, graphic and so on.
6. Module design makes module individual and can fix easily without affecting others.
7. LAMP’s outdoor advertising LED display product ranges from pixel 10mm to pixel 62.5mm, IP65 rating outdoor display products that deliver high-resolution full color images with unequalled brightness and contrast levels.
8. The product ranges offer a modular outdoor display concept that allows the build-up of almost any shape and size display that is ideal for use at outdoor locations with large viewing distances.
Applications:
We guarantee all our displays, modules, parts for two full years. During this time, we will replace or amend all our goods for free if there is something wrong with them. We provide lifetime maintenance and charge only for the raw materials. We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory. We also provide the operation manual, software, test report and so on. Any associated CAD drawing on how to fix up the display and some other expert suggestion will be provided.
Technology Training:
1. We provide the technology training for free, which contains the operation training and maintenance training in the factory.
2. We will send our engineers to your country by negotiation.
Documents and Certification:
1. We provide the operation manual, software, test report and so on.
2. We can also provide all kinds of certification such as CE, UL and so on.
CAD Drawing and Fixing:
1. We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
2. We will send our engineers to your place if we are expected after our negotiation.
Additional service:
We provide you the forwarding information, and some other information ,such as flight box, structure information for your reference for free.
We are the professional LED screen service provider, was Established in 2004 with a registered capital of more than $ 10 Million, now ranks the leading manufacturer of LED display. Since its inception, our company has kept rapid growth; Our products have been sold to more than 130 countries and regions, and the brand GBLED has got highly recognition in the world.
As always, on "Action speaks louder than words" as its brand business philosophy. Working hard and being a magnanimous man. We are been utilizing the advanced technologies and pursuing innovation to produce the best quality product, and regarding every order as our vanity project. To make our product perfect, we introduce the most advanced production equipments and detecting facilities, So as to maintain a strict quality standard of every production process. Thanks to those efforts, our products have passed many certificates, such as, CE, UCS, CCC, FCC approval etc.
Our product quality management is strictly adhering to the ISO9001: 2008 certifications system and 7S management standard, to seek for greater perfection, which exerts profound influence on standardization of LED industry.GBLED is a national new high-tech enterprise,which owns number of national patents and has been cited as "Shenzhen Flat Panel Display Industry Association", "Member of Shenzhen SME Development Association", "Member of Semi-conductor and Lighting Promotion Association", "Member of Shenzhen Electronic Chamber of Commerce", "Member of China Optics and Optoelectronics Industry Association and LED Display Applications Branch Association", "Certified Supplier of Made-in-China" etc.
With an outstanding business performance and good social reputation,We has won respect from various circles of society, and acquired the "2009-2010 Excellent LED Display Application Engineering", "China Well-known Enterprise", "AAA Quality, Service and Prestige Unit", "China Top 100 Enterprise", "Guangdong China Top 10 Enterprise", "Shenzhen Well known Brand Enterprise", "National New High-tech Enterprise" etc.
Here we promise that, every client, every order and every feedback will be valued byGift Booking. Let's hand in hand, regarding "Showing the beauty of the world" as our mission, and creating a more colorful and brighter world.
