P10 Full Colorindoor Digital Advertising Display With Die Casting Aluminum Cabinet
Product Details:
Place of Origin: | China |
Brand Name: | GBLED |
Certification: | CE/ROHS/FCC |
Model Number: | P10 |
Payment & Shipping Terms:
Minimum Order Quantity: | Negotiation |
---|---|
Price: | Negotiation |
Packaging Details: | Wooden Case, Flight Case |
Delivery Time: | 10-30 workingdays |
Payment Terms: | T/T, Western Union |
Supply Ability: | 5000sqm per month |
Detail Information |
|||
Module Size: | 320mm*160mm | Pixel Pitch: | 10mm |
---|---|---|---|
Color: | Full Color | Physical Density: | 10000/m2 |
Driving Method: | Constant Current 1/8scan | LED Encapsulation: | 3528 |
Module Port: | HUB-75 | ||
High Light: | indoor led display screen,indoor advertising led display screen |
Product Description
P10 Full Colorindoor Digital Advertising Display With Die Casting Aluminum Cabinet
Specifications:
1. Slim and light.
2. Easy for movement and installation.
3. High refresh rate and brightness.
4. How video in good quality.
P10 LED INDOOR FULL COLOR DISPLAY
Product Features:
1. color spots or picture shade will be removed through the adjustment of brightness and color by each independent pixel.
2 . adopted with self developed steel structure and special kits will be kept in good flatness and smoothness.
3 . strict water proof testing by Ip65.
4 . according to environmental changes the brightness can be adjusted automatically for energy saving.
5 . special PVC kits are adopted to protect from corrosion according to coastal weather.
6 . according to environmental changes the brightness can be adjusted automatically for energy saving.
7 . auto power on/off, work unattended.
※Module Parameter | ||||
Technical parameters | UNIT | parameters Values | ||
Pixel pitch | MM | 10 | ||
Panel size | MM | L320XH160X15 | ||
Physical density | /M2 | 10000Dots | ||
Pixel configuration | R/G/B | 1,1,1 | ||
Driving method | Constant current 1/8scan | |||
LED Encapsulation | SMD | 3528 | ||
Display resolution | DOTS | 32X16=512 | ||
Module weight | KG | 0.4 | ||
Module port | HUB75 | |||
Module working voltage | VDC | 5 | ||
Module consumption | W | 15 | ||
※Screen Paremeter | ||||
Viewing angle | Deg. | H120 V120 | ||
Option distance | M | 10-60 | ||
Driving device | 2016/5020 | |||
Every square metre module | PCS | 19.5 | ||
Maximum power | W/ M2 | 300 | ||
Frame Frequency | HZ | 60 | ||
Refresh frequency | HZ | ≥1000 | ||
Equilibrium brightness | CD/ M2 | ≥800 | ||
Working environment temperature | 0C | -10~60 | ||
Working environment humidity | RH | 10%~70% | ||
Display working voltage | VAC | AC46~54HZ,220V±15%/110V±15% | ||
Colour temperature | 9500K-11500K | |||
Gray scale/color | ≥16.7M color | |||
Input signal | RF S-Video RGB etc | |||
Control system | Linsn control system | |||
Mean free error time | HOURS | >5000 | ||
Life | HOURS | 100000 | ||
Lamp failure frequency | <0.0001 | |||
Antijam | IEC801 | |||
Safety | GB4793 | |||
Resist the electricity | 1500V No breakdown | |||
Steel box weight | KG/ M2 | 50(standard steel box) | ||
IP rating | The back IP40,The front IP50 | |||
Steel box size | mm | L960XH960x100 |
FAQ
After Services:
We promise we provide 2 years warranty for free maintain for our products and full life tracking service.
1. During the warranty period, we will repair the equipment free of charge unconditionally if the problem is caused by product quality or production and installation problem.
2. When the warranty expires. we continue to provide maintenance service for whole life of the equipment with relative service/material cost paid.
3. Updating software service is free of charge.
4. Quick respond and repair and help promised by sending technicians to help test and repair on site within 36 hours after customer’s request.
5. We will finish repairing within 5 days after defective equipment sent back to us
• Site instruction service of installation is available.
Basic promise :
A: Full automatic production to control our high quality, best color consistency and get better performance.
B: Energy saving, low power consumption and long lifespan 100,000 hours (about 10 years).
C: We guarantee that the equipment we provide are brand new, complete and unused.
D: Good heat dissipation capability and high waterproof because of the unique design of vent fan (like shutter).
E: Our quality control throughout every process from materials-production- test-package-delivery.
Our company:
We are the professional LED screen service provider, was Established in 2004 with a registered capital of more than $ 10 Million, now ranks the leading manufacturer of LED display. Since its inception, our company has kept rapid growth; Our products have been sold to more than 130 countries and regions, and the brand GBLED has got highly recognition in the world.
As always, on "Action speaks louder than words" as its brand business philosophy. Working hard and being a magnanimous man. We are been utilizing the advanced technologies and pursuing innovation to produce the best quality product, and regarding every order as our vanity project. To make our product perfect, we introduce the most advanced production equipments and detecting facilities, So as to maintain a strict quality standard of every production process. Thanks to those efforts, our products have passed many certificates, such as, CE, UCS, CCC, FCC approval etc.
Our product quality management is strictly adhering to the ISO9001: 2008 certifications system and 7S management standard, to seek for greater perfection, which exerts profound influence on standardization of LED industry.GBLED is a national new high-tech enterprise,which owns number of national patents and has been cited as "Shenzhen Flat Panel Display Industry Association", "Member of Shenzhen SME Development Association", "Member of Semi-conductor and Lighting Promotion Association", "Member of Shenzhen Electronic Chamber of Commerce", "Member of China Optics and Optoelectronics Industry Association and LED Display Applications Branch Association", "Certified Supplier of Made-in-China" etc.
With an outstanding business performance and good social reputation,We has won respect from various circles of society, and acquired the "2009-2010 Excellent LED Display Application Engineering", "China Well-known Enterprise", "AAA Quality, Service and Prestige Unit", "China Top 100 Enterprise", "Guangdong China Top 10 Enterprise", "Shenzhen Well known Brand Enterprise", "National New High-tech Enterprise" etc.
Here we promise that, every client, every order and every feedback will be valued byGift Booking. Let's hand in hand, regarding "Showing the beauty of the world" as our mission, and creating a more colorful and brighter world.
