P3.84mm 1/15 Scan LED Display Cabinet Lightweight For Vocal Concert
Product Details:
| Place of Origin: | Shenzhen China |
| Brand Name: | GBLED |
| Certification: | 3C/GMC/ISO9001/CCPC |
| Model Number: | P3.84 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden Case / Flight Case |
| Delivery Time: | 7-15 Working Days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | >350sqm/month |
|
Detail Information |
|||
| Product Name: | LED Display | Application: | Indoor |
|---|---|---|---|
| Size Of Panel: | 288x288 | Resolution: | 150 X 150 |
| Brightness: | 1200cm/d | Feature: | Refresh Rate≥1200. |
| Standard: | 3C/GMC/ISO9001/CCPC | Pixel Density: | 67817 |
| High Light: | stage background led screen,led stage display screen |
||
Product Description
P3.84mm 1/15 Scan LED Display Cabinet Lightweight For Vocal Concert
Description
1. More easy to install.
2. Lower maintenance cost .
3. Combined with the control system which has more than 14bit processing ,effecting a higher gray level. 4. Red,green and blue LED chips incorporated encapsulation ,better perspective. Strong adaption to environment.
5. More fast to assemble .
specifications
1. Indoor led Display technical parameter
|
Pixel Density(pixel/㎡) |
67817 |
|
White Balance Brightness (cd/㎡) |
≥1200(adjustable) |
|
Max Power Consumption |
300W/cabinet |
|
Average Power Consumption |
150W/cabinet |
|
Color Temperature |
3200-9300(adjustable) |
|
View Angle |
Horizontal 110°；Vertical 110° |
|
Best Viewing Distance(m) |
5m—80m |
|
Display Work Method |
1/15 scan |
|
Digital Processing |
14 bit |
|
Gray Scale |
65536 levels per color |
|
Refresh Frequency (Hz) |
≥1200 |
|
Input Signal |
Video: PAL/NTSC Option: VGA , Video , DVD,TV, SDI.HDMI etc |
|
Waterproof |
No |
|
Working Temperature(ºC) |
-20～+45 |
|
Humidity(RH) |
10% - 80% |
|
Stored Temperature (ºC) |
-30～+60 |
|
Lifetime (50%Brightness)(Hours) |
≥100,000 |
|
Input Voltage(VAC) |
AC 220(or 110V) |
|
Input Power Frequency(Hertz) |
50 to 60 |
|
Data Connection |
Super CAT6 Cable or Fiber |
|
Operating System |
Windows(98/2000/XP/Vista) |
|
Blind Spot Rate |
＜0.00001 |
|
Control Distance |
CAT6 cable:150 meters; Single Fiber: Up To 10 Kilometers |
|
Panel Input Format (With Video Processor) |
VGA,DVI,RGBHV, PbPr (HDTV),Composite, S-Video, TV |
|
Earth Leakage Current(mA) |
＜2 |
|
Pixel Configuration |
SMD2121 |
Pixel Pitch | 3.84 mm |
| Module Resolution |
75x75 |
Module Size(W*H) |
288mm x 288mm |
|
Weigth Per Module |
0.76kg |
Max Power Consumption |
65 w |
3. Indoor LED Display Cabinet
|
Cabinet Size(W*H) |
576mm × 576mm |
Module Qty |
4 pcs |
|
Cabinet Resolution |
150 x 150 |
Cabinet Area |
0.332㎡ |
|
Weight Of One Cabinet |
9.4 kg |
Cabinet Pixel |
67817 |
|
Cabinet Flatness |
＜0.2/㎡ |
Cabinet Material |
Die Casting Cabinet |
Applications
This Indoor Full Color LED Display Are Very Popular In Commercial Advertising Field . such as Community, bus station, schools, telecommunications, customs, stadiums, studio,shopping malls, airports, etc;
competitive advantage
1. 24/7 online support service.
2. Good Quality For Every LED Display Product.
3. Good Price.
4. High Quality Driving IC .
5. Red,Green And Blue LED Chips Incorporated Encapsulation ,Better Perspective.
6. Two Years Maintenance Service With Free.
