SMD5050 P16 Transparent Glass Display / 5000 Nit Transparent LED Display Screen
Product Details:
| Place of Origin: | Shenzhen China |
| Brand Name: | GBLED |
| Certification: | 3C/GMC/ISO9001/CCPC |
| Model Number: | P16.0mm |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden Case/ Flight Case |
| Delivery Time: | 7-15 Working Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | >500sqm/month |
|
Detail Information |
|||
| Product Name: | High Brightness P16.0mm LED Led Curtain Display Screen | Pixel Pitch: | 16mm |
|---|---|---|---|
| Size Of Panel: | 480 X160 | Brightness: | 6000 |
| Usage: | Advertising | Pixel Density: | 6944 |
| Weight: | 46 KG For Each Cabinet | ||
| High Light: | clear glass display screen,transparent glass led display |
||
Product Description
SMD5050 P16 Transparent Glass Display / 5000 Nit Transparent LED Display Screen
Description
Panel input format(with video processor), such as ,VGA,DVI,RGBHV, PbPr (HDTV),Composite, S-Video, TV . There are also interfaces for Sound signal and video signal. The gray level si 65536 level, and the brightness, contrast,saturation, chroma can be adjusted by manual and sensor. Show all sort of word, text, graph, picture, video, 2-dimention, 3-dimention cartoon and other information with your PC does synchronously or asynchronously. Can be used outdoor in all kinds of circumstance, and excellent capability of antisepsis, waterproof. More faster to assemble or disassemble it without any tool.
1. The P16 LED
curtain display features light weight and very thin body design. The cabinet weight is only 5.2kg.
2. The anti-reflective masking ensures clearer and more beautiful images.
3. As the display screen is flexible, the maintenance and installation is very convenient.
4. The steel materials with high thickness provide the cabinets with high structural stability. The cabinets won't be deformed even after repeated installation.
5. According to clients' demands, we can offer curtain LED displays with IP67 protection grade for both front and back sides.
6. Constructed using superior quality materials, the product can be utilized in areas with different temperature conditions. In addition to standard products, we can also offer products supporting working temperature from -30℃ to 60℃.
7. We provide our products with 2-year warranty and lifetime maintenance, and we can also offer 24/7 service.
Technical Specifications
| Specifications | Parameters |
| Model No. | P16 |
| Pixel Pitch | 16mm |
| Brightness | ≥5000nit |
| Pixel Configuration | SMD5050 |
| Pixel Density | 3906 Pixels/sqm |
| Viewing angle (min. 50% brightness) | Horizontal: 120 degree (+60/-60) Vertical: 80degree (+40/-40) |
| Lifetime (full white – 50% brightness) | ≥75,000 Hours |
| Power consumption | Max.: 770W / m2 Average: 310W / m2 |
| Refresh frequency | ≥1000Hz |
| Weight/cabinet | 5.2kg |
| Control system | Color light System (A5S-PRO) |
| Cabinet size | 512mm (W)×512mm (H)×55.5mm (D) |
| Recommended viewing distance | ≥18m |
| Ingress protection | IP67/IP54(front/rear) |
| Transparent rate | 21% |
| Operating environment | Temperature: -20℃～+60℃; Humidity: 10%～95% |
| Input voltage | 110~230V/AC(±10%) |
| Input power frequency | 50/ 60Hz |
| Control system constitution | Main controller + Branch controller + DVI card + CAT5/Fiber |
| Video input | DVI, HDMI, PAL/NTSC/SECAM; S-Video; VGA; RGB; Composite Video; SDI etc. |
| Transmission distance | Multi mode fiber< 500m,Single mode fiber < 30Km, internet cable < 100m |
Our company
Our product quality management is strictly adhering to the ISO9001: 2008 certifications system and 7S management standard, to seek for greater perfection, which exerts profound influence on standardization of LED industry.GBLED is a national new high-tech enterprise,which owns number of national patents and has been cited as "Shenzhen Flat Panel Display Industry Association", "Member of Shenzhen SME Development Association", "Member of Semi-conductor and Lighting Promotion Association", "Member of Shenzhen Electronic Chamber of Commerce", "Member of China Optics and Optoelectronics Industry Association and LED Display Applications Branch Association", "Certified Supplier of Made-in-China" etc.
With an outstanding business performance and good social reputation,We has won respect from various circles of society, and acquired the "2009-2010 Excellent LED Display Application Engineering", "China Well-known Enterprise", "AAA Quality, Service and Prestige Unit", "China Top 100 Enterprise", "Guangdong China Top 10 Enterprise", "Shenzhen Well known Brand Enterprise", "National New High-tech Enterprise" etc.
competitive advantage
1. Good Sevice , 24/7 online support service.
2. Good Quality For Every LED Display Product.
3. Good Price.
4. High Quality Driving IC .
5. Red,Green And Blue LED Chips Incorporated Encapsulation ,Better Perspective.
6. Two Years Maintenance Service With Free.
