• High Brightness P2.5 Stage Rental LED Display Customzied 160mm X 160mm Module
High Brightness P2.5 Stage Rental LED Display Customzied 160mm X 160mm Module

High Brightness P2.5 Stage Rental LED Display Customzied 160mm X 160mm Module

Product Details:

Place of Origin: China
Brand Name: GBLED
Certification: CE/ROHS/FCC
Model Number: P2.5

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Wooden case, Flight case
Delivery Time: 10-30 working days( depond on your quantity)
Payment Terms: T/T, Western Union
Supply Ability: 10000 sqm per month
Get Best Price Contact Now

Detail Information

Pixel Pictch: 2.5mm Module Size: 160*160mm
Brightness: 1000 Driving Method: Constant Current 1/32scan
Module Port: HUB75-D Module Working Voltage: 5V
Module Consumption: 20W
High Light:

stage background led screen

,

led stage curtain screen

Product Description

High Brightness P2.5 Event Large LED Screen Hire Customzied 160mm X 160mm Module



Application area:

1 .  Full color LED display : Equally or compactly make the red, green, blue color in one dot, equally distribute at the panel, so make the whole display
2 .  Usually apply for physical sports, advertisement, bank, stock exchange, station, port, marketplace, telecommunication, department, school, monitor, restaurant, entertainment,


※Module Parameter
 Technical parameters UNIT  parameters values
Pixel pitctMM2.5
Panel sizeMML160*H160*T12
Physical density/M2160000
Pixel configurationR/G/B1,1,1
Driving method Constant current 1/32scan
LED EncapsulatioSMD1515/2121 black
Display resolutionDOTS64X64=4096
Module weightKG0.15
Module port HUB75-E
Module working voltageVDC5
Module consumption W≤20
※Screen parameter
Viewing angleDeg.120
Option distanceM2.5-35
Driving device 20167/2017
Every square metre modulePCS39
Maximum powerW/ M2780
Frame FrequencyHZ≥60
Refresh frequencyHZ≥600
Equilibrium brightnessCD/ M2≥1000(black)
Working environment temperature0C-10~60
Working environment humidityRH10%~70%
Display working voltageVACAC46~54HZ,220V±15%/110V±15%
Colour temperature 8500K-11500K
Gray scale/color ≥16.7M color
Input signal RF S-Video RGB etc
Control system PCTV,nonlinearity card,display card,Linsn control system
Mean free error timeHOURS>5000
LifeHOURS100000
Lamp failure frequency <0.0001
Antijam IEC801
Safety GB4793
Resist the electricity 1500V last 1min,No breakdown
IP rating The back IP40,The front IP50
 mmL480XH480X80





1. Ultrathin and lightweight: aluminum cabinet, easy to install and transport
2. OEM cabinet size: cabinet size is adjustable and compatible with different pixels.
3. New design: combine the advantages of Die-casting Aluminum and Duralumin, using die-casting Aluminum process on the four corners of cabinet to improve precision and guarantee seamless assembling. In the meantime, cost is low.
4. Fast Installation and disassembling: connection lock between cabinets are patented, closely combined, safe, reliable and adjustable
5. Unique blanking circuit: high definition display by eliminating the row/line after-image without damaging the LED lamps.
6. Energy saving: low electric current, high-bright lamps, equipped with PFC switching power supply, save 30% electricity.
7. High refresh rate, high gray level: It can reach 16bit by using PWM driving IC, refresh rate is more than 4000HZ, the gray level is still high even under the condition of low brightness
8. Color correction: support dot-to-dot correction, guarantee the consistency of LED color and brightness, No chromatic aberration for new screens.
9. Dual back-up: both power supply and system dual back-up are optional, reliable performance.


Jinhe After Services:

• Telephone investigation: Our after sales team will call the user every month during the warranty period to follow up the working condition of the products, and to discover and solve problems, if necessary.

• Free guarantee repair (including labor and material); free repair service during the quality warranty period and reasonable charge for spare parts and maintaining service after the quality warranty period. We will never exempt our responsibilities on product owned defects.

• Responding time: upon receiving user’s notification, we ensure 24-hour after-sales technical support.

• Spare parts: necessary spare parts are provided together with products to customers.

• Free technical training: integrative and normative technology training is available for free to customers by our technical personnel to ensure they are skilled in regular operations of hardware and software of products and they are able to estimate and solve small problems.

• Software upgrade: lifelong maintenance of controlling system, incessant improvement of the system functions and continuous software upgrades.

• Site instruction service of installation is available.
