Events Stage Rental LED Display Full Color P7.62 Fast Install For Department / School
Product Details:
| Place of Origin: | China |
| Brand Name: | GBLED |
| Certification: | CE/ROHS/FCC |
| Model Number: | P7.62 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden case, flight case |
| Delivery Time: | 15 working days after receiving the deposit |
| Payment Terms: | T/T, Western Union |
|
Detail Information |
|||
| Pixel Pitch: | 7.62 Mm | Module Size: | 244 * 244 Mm |
|---|---|---|---|
| Scan Mode: | 1/8 Scanning | Module Resoultion: | 32 * 32 |
| Cabinet Type: | Rental Aluminum | Cabinet Size: | 976 * 976 Mm |
| High Light: | led stage curtain screen,led stage display screen |
||
Product Description
Events Rental LED Screens Full Color P7.62 Fast Install For Department / School
Applications:
1: Full color LED display: Equally or compactly make the red, green, blue color in one DOT, equally distribute at the panel, so make the whole display
2: Usually apply for physical sports, advertisement, bank, stock exchange, station, port, marketplace, telecommunication, department, school, monitor, restaurant, entertainment.
3: Wide adjustability range allows the user to regulate the display brightness for all environmental conditions.
4: Good uniformity and consistency provides for an amazingly sharp, vivid and clear Image.
5: Wide viewing angle up to 110 degrees horizontal and 60 degrees vertical
6: Low energy consumption and rapid heat dissipation aid in extending the product life span.
7: Easy to maintain with simple LED module replacement.
8: Using SMT or AI automatic production line reduces manufacturing variation and improves product quality.
9: Unique cabinet design allows for quick assembly and disassembly; especially for temporary exhibits and renting
Specifications:
| Items | P7.62 Indoor Full Color Display | |
| Module | Pixel Pitch | 7.62mm |
| Pixel Density(dot/m²) | 17222 | |
| Pixel Configuration | 1R1G1B | |
| Packaged Type of LED | SMD | |
| Module Size(mm) | 244 * 244 or 488 * 244 mm | |
| Module Resolution | 32 * 32 or 64 * 32 | |
|
Technical |
Brightness(cd/m²) | 3500 |
| Max Power Consumption(w/m²) | 700 | |
| Best Viewing Distance(m) | 7-21 | |
| Viewing Angle | 120°V/120°H | |
| Drive Mode | Constant Current drive 1/8 scan | |
| Driving | Driving IC MBI5026 / MBI5024 | |
| Frame-change Frequency | ≥60 Hz/s | |
| Refresh Rate | ≥600Hz/s | |
| Gray Grade Level | 4096 grades | |
| Color | 65536kinds of colors | |
| Display Mode | 1024*768 | |
| Control System | Synchronization Control | |
| Transmission Distance | Reticle≤100M;Multi-mode Fiber≤500M;Single-mode Fiber≤10000M | |
| Out of Control | Rate≤0.0001 | |
| Lifespan | ≥100000H | |
| Driving Power | 5V | |
| Working Voltage | AC220V±10% 47HZ~60hz | |
| Working Temperature | -10ºC~+55ºC | |
| Working Humidity | 5%RH~85%RH | |
Features:
1. High-precision optical design of LED, each pixel is integrated by RGB LED chips.
2. High Contrast ratio: above 2000:1 .very high level to ensure a vivid image of our LED display screen system
3. Clear vivid image quality. more than 140 degree in horizontal and vertical to ensure you attract more audience to get short ROI of your LED display screen's investment
4. High definition, from p2.5 to p10, led display with high resolution to keep good video effect
5. Thin cabinet : we have die-case cabinet and new design cabinet for your choose, less than 10kg/pcs
6. Seamless stitching: With a special connector design it is easy to reduce gaps while installing, creating a perfect display.
2) Full automatic production to control our high quality, best color consistency and get better performance.
3) Energy saving, low power consumption and long lifespan 10,000 hours (about 10 years).
4) We guarantee that the equipment we provide are brand new, complete and unused.
5) Good heat dissipation capability and high waterproof because of the unique design of vent fan (like shutter).
6) Our quality control throughout every process from led lamp, module, cabinet to screen. You can find detail description as below
