    Product Details:

    Place of Origin: China
    Brand Name: GBLED
    Certification: CE/ROHS/FCC/SGS
    Model Number: JH-002

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Carton, wooden case, flight case, according to customer’s request.
    Delivery Time: 10 working days after received your payment
    Payment Terms: T/T or western Union
    Supply Ability: 3,000pcs per month
    Contact Now
    Detailed Product Description
    Product Name: Outdoor Led Display Size Of Cabinet: 960mm*800mm
    Brightness: 1200cm/d Physical Density: 10000/M2
    Application: Outdoor Viewing Angle: H120 V120
    Driving Method: Constant Current 1/4scan Resolution Of Cabinet: 96*80

    P10 Video Outdoor Transparent Glass LED Screen CE / ROHS Certification



    Module parameter
    Technical parameters UNIT parameters Values
    Pixel pitch MM 10
    Physical density /M2 10000
    Pixel configuration RGB 1R1G1B
    Driving method   Constant current 1/4scan
    Module resolution DOTS 32X16=512Dots
    Module port   HUB75-D
    Led display parameter
    Viewing angle Deg. H110 V110
    Every square meter module PCS 19.5
    Maximum power W/ M2 800
    Refresh frequency HZ ≥600
    Equilibrium brightness CD/ M2 ≥7000
    Working environment temperature 0C -30~+65
    Working environment humidity RH 10%-90%
    Gray scale/color   ≥16.7M color
    Input signal   RF S-Video RGB etc
    Life time HOURS 100000
    Lamp failure frequency   <0.0001
    IP rating   IP65






    1. 10000 pixel dots per square meter resolution.

    2. With super-high brightness LED, high contrast.

    3. Unequalled high brightness and stable performance lead long lifespan and low power consumption.Accurate color uniformity and smoother,flicker-free video displaying.

    4. 16,777,216 colors combine with 256 level gray scale by each Red,Green,and Blue LED.

    5. Extreme viewing angle by 3 IN 1 SMD,better color mixture and gorgeous image quality.

    6. Latest LED technology and control method accepted, make excellent performance with attractive price.

    7. With the performance of high brightness, low attenuation, long lifetime and high reliability.

    8. We provide good pre -sale service and after -sale service.





    Business Organizations supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
    Financial Organizations

    Banks, negotiable securities, funds, insurance companies, pawnshops;

    Non-profit Organizations: Telecommunications, post offices, hospital, schools;

    Public Places subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers; Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms
    Entertainments Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course



    Frequently asked questions:


    1. How long have your company run on led display?
    5 years focusing on led display field, 3 years exporting experience.


    2. Which payment terms are you accept?

    T/T, Paypal, Western Union or Bank transfer.


    3. Are your company a trading one or a factory?
    Factory and trade (we have our own factory.)


    4. After an order is placed, when to deliver?
    It depends on whether the products you buy has inventory. If we have inventory, generally we can arrange shipment after 2 to 3 days.If not, it will be decided by the time of the factory production.


    5. What about the cooperation process?
    Confirm details of order, 30% deposit, Arrange inventory, pay the balance, shipment.


    6. What is your terms of delivery?
    After we receive the 30% advance , 5days~15 days later can load goods



    Our company


    We are the professional LED screen service provider, was Established in 2004 with a registered capital of more than $ 10 Million, now ranks the leading manufacturer of LED display. Since its inception, our company has kept rapid growth; Our products have been sold to more than 130 countries and regions, and the brand GBLED has got highly recognition in the world.
