• DIP Largest Video Screen / P10 Outdoor Full Color LED Display Module Saving Engergy
DIP Largest Video Screen / P10 Outdoor Full Color LED Display Module Saving Engergy

DIP Largest Video Screen / P10 Outdoor Full Color LED Display Module Saving Engergy

Product Details:

Place of Origin: China
Brand Name: GBLED
Certification: CE/RoHS/FCC/ETL etc.
Model Number: E1000D

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Flight case or wooden box
Delivery Time: 15 working days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 5000 sqms per month
Get Best Price Contact Now

Detail Information

Pixel Pitch (mm): 10.0 Configuration: DIP346
Gray Scale(bit): 14 Scanning: 1/4
Module Weight(kg): 2.08 Panel Weight(kg): 50
High Light:

stadium led screens

,

stadium display screen

Product Description

Front Maintance Stadium LED Display 10mm With Large Viewing Angle



Features:

1. High Brightness and Saving Engergy
Outdoor HD led display leader,very mature product,each type is at least 2 years ahead of the industry. Using the high brightness led light with the lowest consumption, saving engergy ≥30%, with 28 core technologypatent, whole saving engergy≥50%, energy saving and environment protection.
Adopt general led module series with core technology, make it possible for customer to upgrade the screen to smaller pixel pitch,Increase the secondary marketing opportunity and maintain good relationship.
2. Support Format Low Cost Installation
Broadct color gamut, intelligent adjustment for color temperature and brightness.Uniform color, high contrast, the picture is vivid and nature. Support main displaying format, workable for DVI HDMI 3G/HD/SD SDI display format. Modularized design,low cost for installation and maintenance, easy to operate,support hot plugging.


Specification:

Model

E1000D

Pixel pitch (mm)

10.0

Configuration

DIP346

Module dimension (mm)

320 x 320

Module weight(kg)

2.08

Panel dimension(mm)

1280x960x120

Panel weight(kg)

50

Pixel density(dots/㎡)

10000

Flatness error(mm)

≤0.1

Viewing angle(°)

140/100(Horizontal/Vertical)

Brightness(cd/㎡)

>7500

Contrast

4000:1

Repetition frequency(Hz)

50/60

Refresh frequency(Hz)

1920

Gray scale(bit)

14

Ave. power(W/㎡)

200

Max power(W/㎡)

698

Working temp./humidity

-20~65℃/10%~90%RH

Storing temp./humidity

-20~65℃/10%~90%RH

Protection

IP65/IP54

Scanning

1/4

Power requirements

AC90~264V, 47~63Hz

Signal Transmission Distance

CAT cable:<100m;Single mode fiber:<10km

Installation type

Fix

Life time(hrs)

100,000

Certificate

CCC/TUV-CE/ETL, etc.























Description:

1) Strong centralized control technology, Equipment is simple and complete
2) Software environment
3) Multimedia structure, screen directly controlled by the computer
4) Real-time 256 degree gray, reflect the true colors
5) Brightness adjustment
6) Support for multiple display mode

7) Contrast, brightness adjustment of the entire screen ion of Tube Core
8) The size and style can be customized as the requirements of customers


Advantage:
1) Price: we have the best competitive price, also have the same even better quality.
2) Performance Advantage: Best Equality, high consistency, Big viewing angle
3) Quality: We control all steps, that's the guarantee of the quality
4) Service : Better service at same situation, better cooperation at same service!


Service:
1) Your inquiry related to our products or price will be replied in 24hrs

2) OEM&ODM,any your customized lightings we can help you to design and put into product

3) Distributoership are offered for your unique design and some our current models

4) Protection of your sales area,ideas of design and all your private information

After-Sale Service
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.

Applications:

The stadium led displays are widely used in the football field, basketball court , swimming center and diving center.

1.  Show function(advertising, such as Nike, Coca cola,etc)

2.  Function of time and score(live showing the score)
