Outdoor Fixed Full Color Stadium LED Screen 10mm For Sport Games , high refresh rate
Product Details:
| Place of Origin: | China |
| Brand Name: | GBLED |
| Certification: | CE/RoHS/FCC/ETL etc. |
| Model Number: | E1000D |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Flight case or wooden box |
| Delivery Time: | 15 working days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 5000 sqms per month |
|
Detail Information |
|||
| Pixel Pitch (mm): | 10.0 | Configuration: | DIP346 |
|---|---|---|---|
| Module Dimension (mm): | 320 X 320 | Module Weight(kg): | 2.08 |
| Panel Dimension(mm): | 1280x960x120 | Panel Weight(kg): | 50 |
| High Light: | stadium led screens,stadium display screen |
||
Product Description
Outdoor Fixed Full Color Stadium LED Screen 16mm For Sport Games
Features:
- Classical structure and long-term verification,solid and stable.
- Integrating LED and IC in 1 PCB,further improve stability and ability of heat radiation.
- Inner circuit,effectively reducing the influence of natural factors to line connection.
- Supporting MBI5035 IC and PFC power supply,energy saving up to 50% and more.
- Ideal parameter setting,effectively slowing down the speed of brightness and color reduction.
Specification:
|
Model |
E1000D |
|
Pixel pitch (mm) |
10.0 |
|
Configuration |
DIP346 |
|
Module dimension (mm) |
320 x 320 |
|
Module weight(kg) |
2.08 |
|
Panel dimension(mm) |
1280x960x120 |
|
Panel weight(kg) |
50 |
|
Pixel density(dots/㎡) |
10000 |
|
Flatness error(mm) |
≤0.1 |
|
Viewing angle(°) |
140/100(Horizontal/Vertical) |
|
Brightness(cd/㎡) |
>7500 |
|
Contrast |
4000:1 |
|
Repetition frequency(Hz) |
50/60 |
|
Refresh frequency(Hz) |
1920 |
|
Gray scale(bit) |
14 |
|
Ave. power(W/㎡) |
200 |
|
Max power(W/㎡) |
698 |
|
Working temp./humidity |
-20~65℃/10%~90%RH |
|
Storing temp./humidity |
-20~65℃/10%~90%RH |
|
Protection |
IP65/IP54 |
|
Scanning |
1/4 |
|
Power requirements |
AC90~264V, 47~63Hz |
|
Signal Transmission Distance |
CAT cable:<100m;Single mode fiber:<10km |
|
Installation type |
Fix |
|
Life time(hrs) |
100,000 |
|
Certificate |
CCC/TUV-CE/ETL, etc. |
Advantage:
1. New soft mask design ,special soft pad design
2. Adjustable gradient of cabinet (75°~90°)
3. Pyrolytic coating technology for cabinet
4. Excellent waterproof , dustproof and antirust features
5. IP65, high refresh rate assured perfect image
6. All-weather working , and keep good performance in any outdoor environment
7. Quite fit for indoor and outdoor court applying
Service:
1) Reply your inquiry in 24 working hours.
2) Experienced staffs answer all your query in fluent English,Spanish,French,German etc
3) Customized design is available,OEM & ODM are welcomed.
4) Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
5) Special discount and protection of sales area provided to our distributor.
6) Warmly welcome your visit in our company if available.
7) Warranty: 24 months, a little investment for longer warranty time.
