Perimeter sports led display Indoor / Stadium Advertising outdoor led screen rental Boards
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | GBLED |
| Certification: | CE,ROHS |
| Model Number: | S6 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | wooden case or flight case |
| Delivery Time: | 15 days |
| Payment Terms: | L/C, D/A, D/P, D/P, T/T, Western Union |
| Supply Ability: | 1000 sqm/per month |
|
Detail Information |
|||
| Pixel Pitch: | 6mm | Pixel Package: | 3528 |
|---|---|---|---|
| Module Size: | 192X192mm | Cabinet Material: | Iron Or Aluminum |
| Cabinet Weight: | 1500nit | Driving Mode: | 1/8 |
| Refresh Rate: | 1920~3840Hz | Actual Use Power: | 120-180W/m2 |
| High Light: | stadium led screens,stadium advertising boards |
||
Product Description
Perimeter sports led display Indoor / Stadium Advertising outdoor led screen rental Boards
Features:
1. Support multimedia files.
2. Stadium screen can display various files from words,image,to video.
3. More clear, more vivid, higher definition.
Applications:
Apply to all indoor sport stadiums, like basketball, hokey, volleyball, ping-pong, etc.
Spicifications:
| Product Series | S6 |
| Pixel Pitch | 6mm |
| Pixel Package | SMD3528 |
| LED Configuration | 1R1G1B |
| Pixel Density | 40,000 Pixels/㎡ |
| Module Size | 192mm x 192mm |
| Module Resolution | 32 x 32 dots |
| Suggested Cabinet Size | 960mm x 960mm x 150mm |
| Cabinet Resolution | 160 x 160 dots |
| Cabinet Material | Iron / Aluminum |
| Brightness | ≥ 1500 nits |
| Color Temperature | 3000-12000K |
| Viewing Angle | H-140°/ V-140° |
| Driving Mode | 1/8 |
| Refresh Rate | 1920-3840Hz |
| Frame Frenquency | 60Hz |
| Grey Level | 4096~65536 |
| Number of Color | ＞1 billion |
| Maximum Power Consumption | 350 W/㎡ |
| Average Power Consumption | 120~180 W/㎡ |
| Input Voltage | AC220±10%, AC110 ±10% |
| Input Frequency | 50-60Hz |
| External Interface | S-video, VGA, DVI, SDI, CVBS, YPrPb, HDMI, etc |
| IP Rating | IP31 |
Our Services:
Two-year quality warranty with lifelong maintenance.
Free guarantee repair (including labor and material); free repair service during the quality warranty period and reasonable charge for spare parts and maintaining service after the quality warranty period. We will never exempt our responsibilities on product owned defects.
Responding time: upon receiving user’s notification, we ensure 24-hour after-sales technical support.
Spare parts: necessary spare parts are provided together with products to customers.
Free technical training: integrative and normative technology training is available for free to customers by our technical personnel to ensure they are skilled in regular operations of hardware and software of products and they are able to estimate and solve small problems.
Telephone investigation: our after-sales team will phone the user every month during the warranty period to follow up the working condition of the products, and to discover and solve problems, if necessary.
Software upgrade: lifelong maintenance of controlling system, incessant improvement of the system functions and continuous software upgrades.
Site instruction service of installation is available.
Free on-site service for hardware related issues .
