P7.62 Bracket Mount Outdoor SMD LED Display SMD2121 488X244MM

P7.62 Bracket Mount Outdoor SMD LED Display SMD2121 488X244MM

    • P7.62 Bracket Mount Outdoor SMD LED Display SMD2121 488X244MM
    • P7.62 Bracket Mount Outdoor SMD LED Display SMD2121 488X244MM
    • P7.62 Bracket Mount Outdoor SMD LED Display SMD2121 488X244MM
  • P7.62 Bracket Mount Outdoor SMD LED Display SMD2121 488X244MM

    Product Details:

    Place of Origin: Shenzhen China
    Brand Name: GBLED
    Certification: 3C/GMC/ISO9001
    Model Number: P7.62

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Wooden Case / Flight Case
    Delivery Time: 10-20 Working Days
    Payment Terms: T/T, L/C
    Supply Ability: >300sqm/month
    Contact Now
    Detailed Product Description
    Product Name: LED Display Application: Indoor
    Size Of Panel: 244x122 Resolution: 64x32
    Brightness: 1500cm/d Refresh Frequency: ≥800.
    Structure: Bracket Mount



    P7.62 Bracket Mount Indoor LED Display Module SMD3528 244X244mm



    Description

    Higher cost performance.  Lower maintenance cost . Combined with the control system which has more than 14bit processing ,effecting a higher gray level.  Red,green and blue LED chips incorporated encapsulation ,better perspective. Strong adaption to environment.  More faster to assemble or disassemble it without any tool.  It uses SMD3528 LED light, Taiwan Epistar chip and full glass fiber interior heat dissipation thickened ground lead, so that the electricity current and brightness can be adjusted on line, and the grey scale of the message display signs will not be influenced.


    specifications

    1.  Indoor led Display technical parameter

    Pixel Density(pixel/㎡)

    17222

    White Balance Brightness (cd/㎡)

    ≥1500(adjustable)

    Max Power Consumption

    550Wsqm

    Average Power Consumption

    300W/sqm

    Color Temperature

    3200-9300(adjustable)

    View Angle

    Horizontal 120°;Vertical 120°

    Best Viewing Distance(m)

    7m

    Display Work Method

    1/8 scan

    Digital Processing

    14 bit

    Gray Scale

    65536 levels per color

    Refresh Frequency (Hz)

    800

    Input Signal

    Video: PAL/NTSC  Option: VGA , Video , DVD,TV,
    SDI.HDMI etc

    Waterproof

    No

    Working Temperature(ºC)

    -20~+45

    Humidity(RH)

    10% - 80%

    Stored Temperature (ºC)

    -30~+60

    Lifetime (50%Brightness)(Hours)

    ≥100,000

    Input Voltage(VAC)

    AC 220(or 110V)

    Input Power Frequency(Hertz)

    50 to 60

    Data Connection

    Super CAT6 Cable or Fiber

    Operating System

    Windows(98/2000/XP/Vista)

    Blind Spot Rate

    <0.00001

    Control Distance

    CAT6 cable:150 meters;  Single Fiber: Up To 10 Kilometers

    Panel Input Format (With Video Processor)

    VGA,DVI,RGBHV, PbPr (HDTV),Composite, S-Video, TV

    Earth Leakage Current(mA)

    <2


    2.  Indoor LED Display Module

    Pixel Configuration

    SMD3528

    Pixel Pitch 7.62 mm
    Module Resolution

    32x16

          Module Size(W*H)

    244mm x 122mm

    Weigth Per Module

    0.23kg

    Max Power Consumption

    15w


    3.  Indoor LED Display Cabinet

    Cabinet Size(W*H)

    244mm × 244mm

    Module Qty

    4 pcs

       Cabinet Resolution

    64 x32

    Cabinet Area

    0.1190

    Weight Of One Bracket Mount

    1.0 kg

    Cabinet Pixel

    17222

    Cabinet Flatness

    <0.2/㎡

    Cabinet Material

    Bracket Mount



    Applications

     Commercial advertising, Stadium perimeter, mobile media, night club, entertainment events, business establishments, such as banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio, shopping malls, railways, airports, harbors, etc;


    competitive advantage


    1.  Good Sevice , 24/7 online support service.
    2.  Good Quality For Every LED Display Product.
    3.  Good Price.
    4.  High Quality Driving IC .
    5.  Red,Green And Blue LED Chips Incorporated Encapsulation ,Better Perspective.
    6.  Two Years  Maintenance Service With  Free.
