P5 Outdoor LED Display Screen Cabinet With NOVA Control System For Club / Hotel

P5 Outdoor LED Display Screen Cabinet With NOVA Control System For Club / Hotel

P5 Outdoor LED Display Screen Cabinet With NOVA Control System For Club / Hotel

Product Details:

Place of Origin: Shenzhen China
Brand Name: GBLED
Certification: 3C/GMC/ISO9001/CE
Model Number: P5

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Wooden Case / Flight Case
Delivery Time: 10-20 Working Days
Payment Terms: T/T, L/C
Supply Ability: >300sqm/month
Contact Now
Detailed Product Description
Product Name: LED Display Application: Indoor
Size Of Panel: 240x240 Resolution: 120x120
Brightness: 1200cm/d Refresh Frequency: ≥1200.
Type: Rental



P5 Indoor SMD LED Display Cabinet with NOVA Control System For Club / Hotel



Description

Higher cost performance.  Lower maintenance cost . Combined with the control system which has more than 14bit processing ,effecting a higher gray level.  Red,green and blue LED chips incorporated encapsulation ,better perspective. Strong adaption to environment.  More faster to assemble or disassemble it without any tool.  It uses SMD2121 LED light, Taiwan Epistar chip and full glass fiber interior heat dissipation thickened ground lead, so that the electricity current and brightness can be adjusted on line, and the grey scale of the message display signs will not be influenced.


specifications

1.  Indoor led Display technical parameter

Pixel Density(pixel/㎡)

40000

White Balance Brightness (cd/㎡)

≥1200(adjustable)

Max Power Consumption

300W/cabinet

Average Power Consumption

150W/cabinet

Color Temperature

3200-9300(adjustable)

View Angle

Horizontal 110°;Vertical 80°

Best Viewing Distance(m)

5m—100m

Display Work Method

1/12 scan

Digital Processing

14 bit

Gray Scale

65536 levels per color

Refresh Frequency (Hz)

≥1200

Input Signal

Video: PAL/NTSC  Option: VGA , Video , DVD,TV,
SDI.HDMI etc

Waterproof

No

Working Temperature(ºC)

-20~+45

Humidity(RH)

10% - 80%

Stored Temperature (ºC)

-30~+60

Lifetime (50%Brightness)(Hours)

≥100,000

Input Voltage(VAC)

AC 220(or 110V)

Input Power Frequency(Hertz)

50 to 60

Data Connection

Super CAT6 Cable or Fiber

Operating System

Windows(98/2000/XP/Vista)

Blind Spot Rate

<0.00001

Control Distance

CAT6 cable:150 meters;  Single Fiber: Up To 10 Kilometers

Panel Input Format (With Video Processor)

VGA,DVI,RGBHV, PbPr (HDTV),Composite, S-Video, TV

Earth Leakage Current(mA)

<2


2.  Indoor LED Display Module

Pixel Configuration

SMD3528

Pixel Pitch 5 mm
Module Resolution

48x48

      Module Size(W*H)

240mm x 240mm

Weigth Per Module

0.47kg

Max Power Consumption

45w


3.  Indoor LED Display Cabinet

Cabinet Size(W*H)

480mm × 480mm

Module Qty

4 pcs

   Cabinet Resolution

96 x 96

Cabinet Area

0.2304

Weight Of One Cabinet

7.8 kg

Cabinet Pixel

40000

Cabinet Flatness

<0.2/㎡

Cabinet Material

Die Casting Cabinet



Applications

 Commercial advertising, Stadium perimeter, mobile media, night club, entertainment events, business establishments, such as banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio, shopping malls, railways, airports, harbors, etc;


competitive advantage


1.  Good Sevice , 24/7 online support service.
2.  Good Quality For Every LED Display Product.
3.  Good Price.
4.  High Quality Driving IC .
5.  Red,Green And Blue LED Chips Incorporated Encapsulation ,Better Perspective.
6.  Two Years  Maintenance Service With  Free.
